SLZN 84A
Automatic wall-mounted soap dispenser behind mirror, 24 V DC
Characteristics
- includes Bluetooth control (paid Sanela Control app available for download)
- automatic wall-mounted soap dispenser behind mirror
- inner plastic container ABS
- mounting behind mirror
- easy soap refilling
- soap economy
- one dose of soap is flowing as hands are in the active range under the mirror (can be set in range 1,3 - 13 s), standard 2,6 s
- use in the public sector, container for soap 5 l
- parameter setting and communication with the electronics via the Sanela Control app (Bluetooth) or the SLD 03
- material stainless steel AISI 304 (1.4301)
- Order number: 85840
I am interested in more information:
Supply specification
SLZN 84A - Supply No. 85840 - stainless steel mounting holder with soap dipenser and electronics including Bluetooth module, inlet hoses, pump for liquid soap, container for soap 5 l
Technical information
| Dimensions: | 330 x 200 x 300 mm |
| Weight: | 1,6 kg |
| Thickness of stainless steel material: | 1 mm |
| Volume: | 5 l |
| Operating voltage: | 24 V DC |
| Power input: |
3 W |
| Active range: | 0,14 - 0,2 m |
| Recommended soap viscosity: | 10 mPa*s - 5000 mPa*s (don‘t use chemical solvents and disinfection) |
Downloads
- Mounting instructions (5.67 MB)
- Catalogue list (248.67 kB)
- 2D Drawing (382.08 kB)
Accessories
Related Products
The display of the products on the website is for information only. The producer reserves the right to make technical changes or parameters. The producer makes every effort to keep the information published here as up-to-date as possible, but does not guarantee that all data is accurate and current at the time.
